1 1/4" x 150 1/2", DAKE LE13A, Horiz. scissors type,5Hp,Mult. stroke,Clamping,230v 3ph   Our stock number: 420039

1 1/4 x 150 1/2 , DAKE LE13A, Horiz. scissors type,5Hp,Mult. stroke,Clamping,230v 3ph

MAKE: DAKE
MODEL: LE13A
Machine Type: Horizontal scissors type
Capacity Bundled:5-¼ inches – 8-½ inches wide, 6-½ inches high
Drop Length Possible:Less than 2 inches
Blade Size: 150-½ inches x 1-¼ inches
Blade Speeds (Feet Per Minute):88 / 130 / 177 / 223 / 262 F.P.M.
Feed Stroke (Single):3/8 inch minimum - 16 inch maximum
Multiple Stroke: 9 times (142 inches maximum)
Feed Type: Hydraulic hitch feed with vertical rollers, feed speed 16 inches in 6 seconds
Length Set Up:Front mounted handwheel, and DRO with large numeral digits.
Horse Power Blade Motor: 5 H.P.
Hydraulic Pump:1 H.P.
Coolant Pump Type: Gear type – 1/8 H.P.
Hydraulic Oil Cap.: 1.2 gallons
Coolant Cap.: 10 gallons
Vises: (Quick set ratchet type)Hydraulic with blade forward clamping for minimized burr and with 1&#
48; throw
Vise Clamping Pressure:600 pounds
Vise Ways: Precision ground and hardened
Work Table: Machined with chip clearance inserts
Hitch Feed Capacity: 3000 pounds with use of roller table
Hydraulic Pump:Hydraulics on demand (HOD) with minimum pressure start up
Head Feed: Hydraulic regulation with RPM compensation feed back
Piece Counter:9999 piece with auto shut off
Rapid Head Approach: Sure stop hydraulically controlled
Blade Tensioning: Mechanical with preset locking ring
Electrical: CE approved / Thermo overload, low voltage protection, 110 control voltage
System Control:PLC
Warning Light:Yes
Auto Shut Off:Pieces reached, out of stock, blade slippage/breakage
Chip Brush:Speed synchronized
Foot Print:82 inches x 75 inches (145 inches deep without roller support)
Roller Support with Vertical Roller Dimensions72 inches long x 16 inches wide
Work Height:21-½ inches
Weight:3290 pounds
Tool Kit:Standard – Includes screw drivers, wrenches and Allan keys
Spare Parts:Standard – Includes chip brushes and guide bearing replacements
Work Light:Standard
Machine Support Pads:Standard
Collective Hour Timer:Standard
Auger Style Chip Removal System: Standard
Guarding: Full hinged
Bundling Vertical Vise:Standard
Lubricant: Flood type unit built into the machine (Electric)
Voltage· Available 230-volt three phase · Available 460-volt three phase (external transf
rmer)Machine should be wired to main service by a qualified Electrician.
AMP· 20-amp service for 230-volt machine· 16-amp service for 460-volt machine
Compressed Air:N/A (Clean, dry)
Operating TemperatureNo special operating temperature level
CUTTING CAPACITIES
90°: 13" rnd, 12" sq,14"x 10"
