13" x 18",KALAMAZOO MS1318SA,BRAND NEW PROMO PRICING,SEMI AUTO WET   Our stock number: 410018

13 x 18 ,KALAMAZOO MS1318SA,BRAND NEW PROMO PRICING,SEMI AUTO WET

MAKE: KALAMAZOO
MODEL: MS1318SA

Drive Motor: 3 Hp (2.2kw)
Hydraulic Motor: .25 Hp (.19kw)
Hydraulic Oil Capacity: 2 gallons (7.5 liters)
Coolant Motor: .125 Hp (.1kw)
Coolant Capacity: 7.8 gallons (7.5 liters)
Blade Speeds (Inf. variable): 102-377 fpm (31-115 mpm)
Blade Size: 1" x .035" x 13'-7"(25 x .9 x 4140mm)
Swivel Angle Range: 0° to 60°
Cutting Capacity
Round @ 90°: 13" (330mm)
Square @90°: 10.6" (270mm)
Rect.@ 90°: 18.5" x 10.6" (470 x 269mm)
Round @ 45°: 11.5" (292mm)
Square @ 45°: 10.5" (268mm)
Rect. @ 45°: 10.5" x 10.5" (268 x 268mm)
Round @ 60°: 8.7" (220mm)
Square @ 60°: 8.7" (221mm)
Rect. @ 60°: 8.7" x 8.7" (220 x 220mm)
Bed Height: 27.5" (700mm)

Dimensions:
Length: 75" (1905mm)
Width: 34" (863mm)
Height: 55.5 (1410mm)
Net Weight: 1,400 lbs (635kg)
Shipping Weight: 1,850 lbs (839kg


FEATURES:
Advanced hydraulic system provides dependable power for powered clamping and raising the saw head at
end of cut

Full stroke machine vise for tight clamping of any material from operator’s panel

Swivel sawhead allows the operator to accurately pivot head for angle cuts from 0°, for a 90
6; cut, to 60°

Carbide blade guides provide excellent stability for the saw blade

Variable blade speed
Power chip brush removes chip from the blade extending blade life

Integrated coolant system

Cast iron moveable guide arms provide rigidity and stability for an accurate cut

Flushing hose

Adjustable work stop

Tool box with tools

Manual & parts list

Two (2) year limited warranty
